Emergency power supply model 1006
Top hat rail installation
Product description
Uninterruptible AC/DC UPS with integrated charging level and battery management, with signal outputs for remote control. Connection terminals for load and battery. For distributor installation.
Operating voltage | 230 V AC/ / ± 15 %; 50/60 Hz |
Output voltage | 24.8 – 27.6 V DC (stabilised) |
Output current | max. 3 A DC (72 W) |
Operation condition | continuous |
Connectable accumulator | 4 – 14 Ah lead-acid batteries |
Recommended accumulator | e.g. FIAMM FG20451 (12 V – 4.5 Ah) or YUASA NP7-12 (12 V – 7 Ah) |
Mounting method | Distributor installation |
Dimension | 210 x 93 x 66.5 mm |
Sub-units | 12 |
Class of protection | IP20 |
Operating temperature range | -10 °C to + 40 °C |
Function indicator | LED |
Outputs for messages | Open-Collector, max. 24 VDC / 30 mA |
Certified in compliance with | DIN EN 62368-1 |
