Steel security fitting with cylinder cover - handle/handle S4K3,VAR=FS

Short backplate for fire doors

Product description

  • Distance 72 mm
  • Spindle 9 mm
  • For cylinder projection from 9 to 13.5 mm
  • External plate thickness 10 mm - Internal plate thickness 6 mm
  • Material external plate: solid steel, hardened
  • Material internal plate: solid steel
  • Double screwed
  • Handle anodised aluminium with steel core
  • Suitable for fire doors

Scope of delivery

  • 1 Set with fixing material

Note

  • The fitting variant VAR=FS is a fire security fitting approved by MPA Dortmund.

Ordering Information

  • Please order VAR=A for use with IKON profile locking cylinders with ARCUS, AEP10 and ASP profiles
Variants that can be ordered
Article numberFB=TS=
S4K3,VAR=FS F1 40
F1 45
F1 50
F1 55
F1 60
F1 65
F1 70
F1 75
F1 80
F1 85
F1 90
F1 95
F1 100
F1 110
F2 40
F2 45
F2 50
F2 55
F2 60
F2 65
F2 70
F2 75
F2 80
F2 85
F2 90
F2 95
F2 100
F2 110
