Backset | 55, 60, 65, 80, 100 mm |
Distance | 72 mm (prepared for Euro profile cylinders) |
Forend | Flat face plate: F3 x 20 mm, F3 x 24 mm, R3 x 20 mm, R3 x 24 mm |
Material face plate | Stainless steel |
Latch | DIN L/R (symmetrical face plate), DIN left or DIN right (asymmetrical face plate according to DIN 18251-1) |
Bolt throw | 20 mm |
Follower | 9 mm |
Standards | EN 1634, EN 15804 |
Monitoring | No |
Top lock | Yes |
door system | Double-leaf door |
Fire protection | Yes |
Panic function | Nein |
Leaf type | Passive leaf |
Door type | Wood/steel wide style |
Functions | mechanical |
Screw type | Mortise lock |
Order number | Forend shape | Forend length | Width face plate | Monitoring |
---|---|---|---|---|
N14200009X*000D | R3 x 20 mm | 235 mm | 20 mm | No |
N14200009X*000E | R3 x 24 mm | 235 mm | 24 mm | No |
