High security multi-point lock 819NE7, electrically handle-controlled

Product description

• The handle-controlled high-security locks and multi-point locks have the same mechanical features and advantages as the 309/319 locks.
• The mechanical self-locking with sequence control reliably prevents unwanted extension of the bolt when the door is open. In addition, the current status of the door is electronically monitored by the integrated electronic control device. It also offers various monitoring functions as well as actuation for the handle coupling.
• The following status queries can be implemented in combination with the ASSA ABLOY IO modules:
• Door status via control latch contact
• Bolt retracted and bolt extended
• Cylinder monitoring
• Handle follower monitoring inside
• Handle follower monitoring outside
• Follower coupling
• The electrical actuation option of the multi-point lock allows operation with access control systems or similar higher-level systems. With the hardened bolts in the main lock and the additional lock cases, extremely high security values in terms of burglary resistance can be achieved in suitable door systems up to RC5.

Overview of Advantages

• Hi-O bus technology for connection to the ASSA ABLOY Hi-O bus system

Note

• All variants listed above are also available with Swiss round cylinders, 94 mm distance!
