Fire protection fittings

J-shaped handle with round knob

ArtNo: H43201150900000
EAN: 4042203783874

Product description

The fire protection fitting for narrow style doors meets requirements for fire and smoke protection hardware in accordance with DIN 18273. The high-quality J-shaped handle on oval rose blends elegantly into any building. Durable brushed stainless steel as a modern and corrosion-resistant material is perfect for any environment where quality matters. This model is supplied with a flat knob.

Overview of Advantages

Freely configurable to your door thickness
Classic curved handle
Meets requirements for fire and smoke protection hardware in accordance with DIN 18273

Note

Compatible with locks of series N1557

Technical data

Exterior escutcheon	Round knob
Protection rating	0
Handle	J-shaped
Type of cylinder	Profile cylinder
spindle	9 mm
Material	Standard, brushed stainless steel
Mounting	Long plate
Distance	92 mm

Accessories/Individual parts

	Order number	Product
	HA32S0000206000	Mounting set narrow style long plate 9 mm half spindle protection rating 2 for door leaf thickness 32-36 mm Protection rating 2 with 9 mm half spindle for door leaf thickness 32-36 mm
	HA32S0000207000	Mounting set narrow style long plate 9 mm half spindle protection rating 2 for door leaf thickness 37-41 mm Protection rating 2 with 9 mm half spindle for door leaf thickness 37-41 mm
	HA32S0000208000	Mounting set narrow style long plate 9 mm half spindle protection rating 2 for door leaf thickness 42-46 mm Protection rating 2 with 9 mm half spindle for door leaf thickness 42-46 mm
	HA32S0000209000	Mounting set narrow style long plate 9 mm half spindle protection rating 2 for door leaf thickness 47-51 mm Protection rating 2 with 9 mm half spindle for door leaf thickness 47-51 mm
	HA32S0000210000	Mounting set narrow style long plate 9 mm half spindle protection rating 2 for door leaf thickness 52-56 mm Protection rating 2 with 9 mm half spindle for door leaf thickness 52-56 mm
	HA32S0000211000	Mounting set narrow style long plate 9 mm half spindle protection rating 2 for door leaf thickness 57-61 mm Protection rating 2 with 9 mm half spindle for door leaf thickness 57-61 mm
	HA32S0000212000	Mounting set narrow style long plate 9 mm half spindle protection rating 2 for door leaf thickness 62-66 mm Protection rating 2 with 9 mm half spindle for door leaf thickness 62-66 mm
	HA32S0000213000	Mounting set narrow style long plate 9 mm half spindle protection rating 2 for door leaf thickness 67-71 mm Protection rating 2 with 9 mm half spindle for door leaf thickness 67-71 mm
	HA32S0000214000	Mounting set narrow style long plate 9 mm half spindle protection rating 2 for door leaf thickness 72-76 mm Protection rating 2 with 9 mm half spindle for door leaf thickness 72-76 mm
	HA32S0000215000	Mounting set narrow style long plate 9 mm half spindle protection rating 2 for door leaf thickness 77-81 mm Protection rating 2 with 9 mm half spindle for door leaf thickness 77-81 mm
