Delta security mortise lock 19421
With latch switching
Overview of Advantages
- Latch switching DIN L/DIN R
- With latch-bolt function
- Version with round cylinder or profile cylinder
- Backset: 25-60mm
- Certification according to EN 1634-1 to 3
- Burglary resistant to class RC2 can be achieved in appropriate door systems
Product description
- Latch switching from DINL to DINR and vice versa possible. A handle is mounted on both sides. The lock is locked with a key.
Area of Application
- Apartments
- Industrial area
- Public buildings
- Metal doors (profile doors)
Note
- Suitable for freewheeling cylinders
- On the frame side, only use bolt switch contact MSL 1886.
| Bolt throw | 20 mm |
| Latch | Reversible |
| DIN-direction | Left / right convertible |
| Latch material | Inox |
| material bolt | Inox |
| Alternative function | Yes |
| Material faceplate | Inox |
| material bolt | Inox |
| Order number | Type of cylinder | Backset | Faceplate dimensions | Forend shape | Follower | DIN-direction |
|---|---|---|---|---|---|---|
| 10201002 | RZ – round cylinder | 25 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201003 | RZ – round cylinder | 30 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201004 | RZ – round cylinder | 35 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201005 | RZ – round cylinder | 40 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201006 | RZ – round cylinder | 50 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201007 | RZ – round cylinder | 60 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201012 | PZ - profile cylinder | 25 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201013 | PZ - profile cylinder | 30 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201014 | PZ - profile cylinder | 35 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201015 | PZ - profile cylinder | 40 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201016 | PZ - profile cylinder | 50 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201017 | PZ - profile cylinder | 60 | 270x24x3 | Square | 9, one-piece | Left / right convertible |
| 10201040 | RZ – round cylinder | 30 | 270x24x6 | U-shaped | 9, one-piece | Left / right convertible |
| 10201041 | RZ – round cylinder | 35 | 270x24x6 | U-shaped | 9, one-piece | Left / right convertible |
| 10201042 | RZ – round cylinder | 40 | 270x24x6 | U-shaped | 9, one-piece | Left / right convertible |
| 10201043 | RZ – round cylinder | 50 | 270x24x6 | U-shaped | 9, one-piece | Left / right convertible |
| 10201044 | RZ – round cylinder | 60 | 270x24x6 | U-shaped | 9, one-piece | Left / right convertible |
| 10201050 | PZ - profile cylinder | 30 | 270x24x6 | U-shaped | 9, one-piece | Left / right convertible |
| 10201051 | PZ - profile cylinder | 35 | 270x24x6 | U-shaped | 9, one-piece | Left / right convertible |
| 10201052 | PZ - profile cylinder | 40 | 270x24x6 | U-shaped | 9, one-piece | Left / right convertible |
| 10201053 | PZ - profile cylinder | 50 | 270x24x6 | U-shaped | 9, one-piece | Left / right convertible |
| | Order number | Product |
|---|---|---|
 | B-19421 | Strike plate |
 | 1886 | Bolt switch contact Frame side 10 m or 20 m |
