Panic security multi-point locking system 1850PE-SV

Overview of Advantages

• With latch-bolt function
• Mechanical automatic locking system
• Deadbolt stroke, single rotation, 20mm each
• Version with round cylinder or profile cylinder
• Backset: 60-80mm
• No
• Certification according to EN 1125
• Certification according to EN 1634-1 to 3
• Intrusion resistance up to Class RC3 achievable in suitable door systems

Product description

• With this automatic locking multi-point lock, a door handle, panic bar or pushbar is used for operation on the inside. On the outside, a bar or knob plate can be mounted depending on the architecture. The inside handle is permanently attached to the lock mechanism and thus enables the lock to be drawn back and the door to be opened from the inside, thus ensuring people can always leave the respective building or area (panic function).

Area of Application

• Entrance and private service doors
• Security doors, escape route and fire doors

Note

• Suitable for freewheeling cylinders
• External bolt switch contacts not permitted
