Panic security multi-point locking system 1856PDe

Overview of Advantages

• Deadbolt stroke, single rotation, 20mm each
• Version with round cylinder or profile cylinder
• Backset: 60-80mm
• No
• Certification according to EN 1125
• Certification according to EN 1634-1 to 3
• Intrusion resistance up to Class RC3 achievable in suitable door systems

Product description

• With this multi-point lock, a door handle is mounted on both sides. The closed door can be opened from the inside via the panic function (inwards opening) in the lock. The spindle (follower) is split with panic function D. After the handle is actuated from the inside, the door can automatically also be opened from the outside, i.e. the handle is engaged on the outside and rescue measures are not obstructed. With this function, locking must always take place with the key again to prevent the door from being opened from the outside.

Area of Application

• Escape door technology in commercial and public buildings with increased security, for new construction and renovations

Note

• Thumbturn cylinders may not be used
• On the frame side, only use bolt switch contact MSL 1886.
• Use special profile half spindle MSL 5968
