Panic security multi-point locking system 1859PBe

Overview of Advantages

• Deadbolt stroke, single rotation, 20mm each
• Version with round cylinder or profile cylinder
• Backset: 60-80mm
• No
• Certification according to EN 1634-1 to 3
• Intrusion resistance up to Class RC3 achievable in suitable door systems

Product description

• With these multi-point locking systems, a door handle is mounted on the inside of the door. A door handle is also mounted on the outside of the door. In unlocked state, the door can be opened from both sides. In locked state, the door can not be opened from the outside, but can always be opened from the inside (panic function inwards opening), the main bolt and the two single-throw bolts are retracted. If the door closes, the lock is locked automatically (automatic locking). The spindle (follower) is split with panic function B. This panic function is suitable for doors that also have to be opened periodically from the outside (daytime operation). Daytime operation can be activated via the cylinder with a key rotation to the stop in the direction of opening, then the door handle on the outside is engaged.

Area of Application

• Entrance and private service doors
• Security doors, escape route and fire doors

Note

• Thumbturn cylinders may not be used
• On the frame side, only use bolt switch contact MSL 1886.
• Use special profile half spindle MSL 5968
