Electric strike 1801
Product description
Special model with monitoring contact and additional integrated monitoring contact in the locking mechanism. Two contacts reliably monitor the door position. When the latch bolt is engaged in the keeper, the door position is checked by the monitoring contact. A second contact monitors the keeper which secures the electric strike latch to establish the locking status of the electric strike latch.
A secured status is only signalled on a door which is secured by an electric strike.
The corresponding Control Panel 7200-20/7200-22 can be used for monitor and control functions.
| Monitoring contact (RR) | Yes |
| Armature contact (AK/RR) | Yes |
| Fail-locked | Yes |
| Break-in resistance | 5000 N |
| Operating temperature range | -15 °C to +40 °C |
| Installation position | Vertical |
| Material housing | Zinc die-cast |
| Latch material | Steel |
| Order number | Description |
|---|---|
| 1801--------E41 | Without strike plate, 12V DC 100% duty cycle |
| 1801--------F41 | Without strike plate, 24V DC 100% duty cycle |
