Electric strike 24.400

Product description

Electric strike for surface-mounted panic door locks with horizontal actuating bar.

Overview of Advantages

  • Due to 180° fitting, can be used DIN right and left
Technical data
Diode (05)Yes
Fail-lockedYes
Hold-open functionYes
ATP (anti-panic)Yes
Break-in resistance3000 N
Height146 mm
Width38 mm
Depth45 mm
Operating temperature range-15 °C to +40 °C
Installation positionVertical and horizontal
Material housingPowder-coated die-cast zinc
Latch materialCoated brass
Variants that can be ordered
Order number
Description
24.400------D11Without strike plate, 6-12 V AC/DC
24.400------R11Without face plate, 8-16 V AC/DC
24.400------F11Without face plate, 24 V AC/DC
24.400------E31Without striking plate, 12 V DC electric unlocking
24.400------F31Without striking plate, 24 V DC electric unlocking
