ePED® CAN connector
Product description
Communication interface between the Hi-O system bus and an automation control via CAN. Based on the CANopen protocol.
| Total power consumption | 0.2 A at 24 V DC |
| Area of application | For indoor use |
| Operating temperature range | -10 °C – +55 °C |
| Connection | Hi-O: 4-wire bus cabling; CAN: electrically isolated, address setting 1…128 |
| Installation | To install flush mounted switch box, 62 mm deep |
| Required power supply | 24 V (±15 %) DC SELV |
| Class of protection | IP30 (wenn vollständig montiert) |
| Amount of bus addresses | 2 |
