Strike plate L4
Standard, M4-compatible dimensions, DIN universal
Product description
Striking plate standard with integrated magnets suitable for Technilock® 844L4, dimensions compatible to striking plate Technilock® M4
Overview of Advantages
- DIN left and right usable
Scope of delivery
- 1 piece strike plate
Note
- *= plate build-up about 26.5 mm. Overall width: 63.5 mm
- *= material thickness + incl. build-up for bolt pocket: 3 mm striking plate shim
| Version | Standard |
| Length | 255 mm |
| Width | 37 mm |
| Thickness | 6 mm |
| Colour | Stainless steel |
| Material | EST: 1.4301 |
| DIN direction | universal |
