Electric strike 118E.15
Without strike plate
Product description
Model with mechanical unlocking (daytime unlocking).
Overview of Advantages
- Radius keeper, FaFix®, adjustable by 3 mm
- Mechanical unlocking (daytime unlocking)
- Voltage range
- Compatible with current mortise locks
- Optimal latch ramps for gentle interaction with the latch bolt
- Symmetrical design. DIN left/right as well as horizontal applicable
Scope of delivery
- 1 piece electric strike
| Mechanical unlocking (E) | Yes |
| Fail-locked | Yes |
| Load cycles for in-plant test | 250000 |
| Installation position | Vertical and horizontal |
| Operating temperature range | -15 °C to +40 °C |
| Break-in resistance | 3750 N |
| Height | 66 mm |
| Suitable for fire doors | No |
| Depth | 25.5 mm |
| Latch bolt engaging depth | 5.5 mm |
| Width | 19.1 mm |
| FaFix® adjustment range | 2 mm |
| Order number | Description |
|---|---|
| 118E.15-----A71 | Without striking plate, 12-24V AC/DC |
| 118E.15-----B71 | Without striking plate, 22-42 V AC/DC |
